* 174PSI/12bar/1200kPa Output pressure
* Fit for almost any size automotive service facility
* Auto-Start Inflation
* Fully Automated, fully programmable, micro-processor controlled conversion system
* Self-diagnostic features
* Suit for: Car, Light Truck, Bus
* 174PSI/12bar/1200kPa Output pressure
* Fit for almost any size automotive service facility
* Auto-Start Inflation
* Fully Automated, fully programmable, micro-processor controlled conversion system
* Self-diagnostic features
* Suit for: Car, Light Truck, Bus
Dimensions (Height*Width*Depth) | 1260mm*360mm*360mm |
Net Weight | 17.5kg/38.6lbs |
Gross Weight | 21kg/44.6lbs |
Packing Size (Height*width*Depth) | 200mm*1290mm*360mm |
Power Requirement | 100-240Vac 50/60HZ |
Power Consumption | 23VA |
Operating Temperature Range | -20℃/-4℉ to 70℃ /158℉ |
Max Inlet Air/ Nitrogen Supply | 217PSI/ 15bar /1500kPa |
Operating Range | 5-174PSI/0.3-12bar/35-1200kPa |
Accuracy | ±1PSI/0.07bar / 7kPa |
Resolution | 1PSI/ 0.1bar /5kPa |
Units of Measurement | PSI/ bar / kPa |
Specifications:
1.Auto-Start inflation
2.Automatic zero drift adjustment
3.Remain at last setting
4.Comprehensive diagnostics and error reporting
5.Audible and visual end of the cycle signal indicators
6.Large backlight LCD display
7.Vandal resistant mechanical switches
8.Suits Standard nitrogen bottle/ Direct nitrogen supply from generator/Air compressor
9.1 Nos.*10M/32.8ft standard hose with single clip-on open type chuck
Operation Steps:
1. Set final target pressure using the +and -buttons.The LCD screen will show the target pressure.
2. Connect air hose to tire valve stem
3. Push the "FILL" button once
4. When unit "beeps" and the LCD screen flashes the target pressure, tire inflation is complete
5. Immediately remove hose
